Setting the Audio Mix

POWER	VCR
	O	F	F
PM
. O
V
SCAN	IE

E

MIX

AUDIO BALANCE

MONITOR ST-1 ST-2

When you play back a tape that was recorded in 12 bit mode, you can set the audio output to play: stereo 1 (the original sound), stereo 2 (any new sound, dubbed to the tape after recording), or mix the balance between the two.

•Audio from the 16 bit mode only contains stereo 1 sound and so you cannot/do not need to select the audio mix. The same is true for the 12 bit stereo 1 mode, unless new sound has been added post-recording.

VCR

Choose the output.

•Press AUDIO MONITOR on the wireless controller.

•Starting with the last selected setting, 4 settings appear as you push the button:

–STEREO1 for just stereo 1.

–STEREO2 for just stereo 2.

–MIX/FIXED for an equal mix of stereo 1 and 2.

–MIX/VARI. (mix variable) for when you want to mix the balance between stereo 1 and 2.

•To simply choose STEREO1, STEREO2 or MIX/FIXED, make sure your choice appears on the display.

•If you choose MIX/VARI., you can go on to mix the balance.

•Use the ST-1/ST-2 keys to mix the balance. A bar showing the mix appears on the screen for 4 seconds.

•When you have chosen the output, STEREO1, STEREO2, MIX/FIXED or MIX/VARI. is shown in the top left of the display for a few seconds. If you turn the power off the output is set to STEREO1.

Editing

91
