Standard audio cable | Dell GU051 specs

1

2

3

1

component video adapter

2

composite video cable

3standard audio cable

1Turn off the computer and the TV and/or audio device that you want to connect.

2Connect the component video adapter to the S-video TV-out connector on the computer.

3Plug all three ends of the component video cable into the component video-output connectors on the component video adapter. Make sure that the red, green, and blue colors of the cable match the corresponding adapter ports.

Using Multimedia

73

Image 73

Dell GU051 manual Standard audio cable
