Dell M630 - page 108

Drives

Internal optional SD card

Optional vFlash card (with integrated iDRAC8

Enterprise)

Connectors

Front

USB One 4-pin, USB 2.0-compliant and one 4-pin,

USB 3.0-compliant

Internal

SD Two internal SD cards dedicated for the

hypervisor

One SD card dedicated for future vFlash support

Mezzanine Cards

Mezzanine slots Two PCIe x8 Gen 3 slots mezzanine card

supporting dual port 10 Gb Ethernet, quad port 1

Gb, FC8 Fiber Channel, FC16 Fiber Channel, or

Infiniband mezzanine cards.

Video

Video type Matrox G200 VGA controller integrated with

iDRAC

Video memory 2 GB shared with iDRAC application memory

Battery

NVRAM backup battery CR 2032 3.0 V lithium coin cell

Environmental specifications

NOTE: For additional information about environmental measurements for specific system

configurations, see dell.com/environmental_datasheets.

Temperature

Storage –40°C to 65°C (–40°F to 149°F)

Continuous operation (for altitude less than 950

m or 3117 ft)

10°C to 35°C (50°F to 95°F) with no direct

sunlight on the equipment.

Fresh air For information on fresh air, see Expanded

Operating Temperature section.

Maximum temperature gradient (operating and

storage)

20°C/h (36°F/h)

108
