System Access configuration

Command: /cfg/sys/access

[System Access Menu]

mgmt

- Management Network Definition Menu

user

- User Access Control Menu (passwords)

http

- Enable/disable HTTP (Web) access

https

- HTTPS Web Access Menu

wport

- Set HTTP (Web) server port number

snmp

- Set SNMP access control

tnport

- Set Telnet server port number

tport

- Set the TFTP Port for the system

cur

- Display current system access configuration

The following table describes the System Access Configuration menu options.

Table 94 System Access Configuration Menu options

Command

Description





mgmt

Displays the Management Configuration Menu.





user

Displays the User Access Control Menu.

http disableenable Enables or disables HTTP (Web) access to the Browser-based Interface. It is enabled by default.

https

Displays the HTTPS Menu.





wport <TCP port

Sets the switch port used for serving switch Web content. The default is HTTP port 80.

number>







snmp disableread-

Disables or provides read-only/write-read SNMP access.

onlyread-write







tnport <TCP port

Sets an optional telnet server port number for cases where the server listens for telnet sessions

number>

on a non-standard port.





tport <TFTP port

Sets an optional telnet server port number for cases where the server listens for TFTP sessions

number>

on a non-standard port.





cur

Displays the current system access parameters.





Management Networks configuration

Command: /cfg/sys/access/mgmt

[Management Networks Menu]

add

- Add mgmt network definition

rem

-

Remove mgmt network definition

cur

-

Display current mgmt network definitions

The following table describes the Management Networks Configuration menu options. You can configure up to 10 management networks on the switch.

Table 95 Management Networks Configuration menu options

Command

Description





add <IP address> <IP mask>

Adds a defined network through which switch access is allowed



through Telnet, SNMP, RIP, or the browser-based interface. A range



of IP addresses is produced when used with a network mask



address. Specify an IP address and mask address in dotted-decimal



notation.





rem <IP address> <IP mask>

Removes a defined network, which consists of a management



network address and a management network mask address.





cur

Displays the current management networks parameters.





Configuration Menu 104

Page 104
Image 104
HP GbE2c manual System Access configuration, Management Networks configuration

GbE2c specifications

The HP GbE2c is a high-performance Ethernet Switch designed to meet the increasing demands of data center environments. As a critical component in Hewlett-Packard's networking lineup, the GbE2c provides a seamless blend of speed, reliability, and advanced networking capabilities, making it an essential tool for enterprises aiming to enhance their network infrastructure.

One of the standout features of the HP GbE2c is its support for Gigabit Ethernet, which allows for high-speed data transmission and reduced latency. This switch is designed to support the growing bandwidth needs of modern applications, ensuring that data is transmitted quickly and efficiently across the network. The GbE2c is particularly beneficial for organizations implementing virtualization technologies, as its Gigabit interfaces help in optimizing data flow between virtual machines.

The GbE2c also incorporates advanced Layer 2 and Layer 3 switching capabilities. This ensures that it can handle both basic and more complex networking tasks, such as routing traffic between different VLANs and enabling Internet Protocol (IP) addressing. The switch supports various protocols, enabling seamless integration into a wide range of network environments.

Additionally, the HP GbE2c is equipped with a robust management system that allows network administrators to easily configure and monitor network settings. With its user-friendly interface, administrators can gain insights into traffic patterns, performance metrics, and potential issues, helping to maintain optimal network performance.

Power efficiency is another key characteristic of the HP GbE2c. The switch is designed to minimize power consumption without sacrificing performance, making it a more sustainable choice for data centers aiming to reduce their carbon footprint. This energy-efficient design is crucial for enterprises looking to lower operational costs while maintaining a high level of service.

The HP GbE2c also boasts high availability features, including redundant power supplies and failover options, ensuring that the network remains operational even in the event of a component failure. This reliability is critical for businesses that require uninterrupted network access for their daily operations.

In summary, the HP GbE2c Ethernet Switch combines speed, versatility, and efficiency, making it an ideal choice for businesses seeking to enhance their networking capabilities. Its robust feature set, advanced management options, and focus on energy efficiency position it as a top-tier solution in the competitive networking landscape. Organizations can rely on the GbE2c to deliver high performance and reliability, thus meeting the demands of today's data-intensive environments.
