IGMP snooping configuration

Command: /cfg/l3/igmp/snoop

[IGMP Snoop Menu]

timeout

- Set report timeout

mrto

- Set multicast router timeout

qintrval

- Set IGMP query interval

robust

- Set expected packet loss on subnet

aggr

- Aggregate IGMP report

srcip

- Set source ip to use when proxying GSQ

add

- Add VLAN(s) to IGMP Snooping

rem

- Remove VLAN(s) from IGMP Snooping

clear

- Remove all VLAN(s) from IGMP Snooping

fastlv

- Enable/disable Fastleave processing in VLAN

cur

- Display current IGMP Snooping configuration

The following table describes the IGMP Snoop Configuration Menu options.

Table 143 IGMP Snoop Menu options

Command

Description





timeout <1-255>

Sets the Maximum Response Time (MRT) for IGMP hosts. MRT is one of the



parameters used to determine the age out period of the IGMP hosts.



Increasing the timeout increases the age out period.



The range is from 1 to 255 seconds. The default is 10 seconds





mrto <1-600>

Configures the age-out period for the IGMP Mrouters in the Mrouter table. If



the switch does not receive a General Query from the Mrouter for mrto



seconds, the switch removes the multicast router from its Mrouter table.



The range is from 1 to 600 seconds. The default is 255 seconds.





qintrval <1-600>

Sets the IGMP router query interval. The range is 1-600 seconds. The default



value is 125.





robust <2-10>

Configures the IGMP Robustness variable, which allows you to tune the



switch for expected packet loss on the subnet. If the subnet is expected to be



lossy (high rate of packet loss), then increase the value. The default value is



2.





aggr disableenable

Enables or disables IGMP Membership Report aggregation.





srcip <IP address>

Configures the source IP address used as a proxy for IGMP Group Specific



Queries.





add <1-4095>

Adds the VLAN to IGMP Snooping.





rem <1-4095>

Removes the VLAN from IGMP Snooping.





clear

Removes all VLANs from IGMP Snooping.





fastlv <1-4095> disableenable

Enables or disables FastLeave processing. FastLeave allows the switch to



immediately remove a port from the IGMP port list, if the host sends a Leave



message, and the proper conditions are met. This command is disabled by



default.





ena

Enables IGMP Snooping.





dis

Disables IGMP Snooping.





cur

Displays the current IGMP Snooping parameters.
