Table 57 IP statistics

Statistics

Description





ipInAddrErrors

The number of input datagrams discarded because the IP address in their IP header



destination field was not a valid address to be received at this switch. This count includes



invalid addresses (for example, 0.0.0.0) and addresses of unsupported classes (for



example, Class E).



For entities which are not IP gateways and therefore do not forward datagrams, this



counter includes datagrams discarded because the destination address was not a local



address.





ipInUnknownProtos

The number of locally addressed datagrams received successfully but discarded because



of an unknown or unsupported protocol.





ipInDiscards

The number of input IP datagrams for which no problems were encountered to prevent



their continued processing, but which were discarded (for example, for lack of buffer



space).



This counter does not include any datagrams discarded while awaiting re-assembly.





ipInDelivers

The total number of input datagrams successfully delivered to IP user-protocols (including



ICMP).





ipOutRequests

The total number of IP datagrams that local IP user-protocols (including ICMP) supplied to



IP in requests for transmission.



This counter does not include any datagrams counted in ipForwDatagrams.





ipOutDiscards

The number of output IP datagrams for which no problem was encountered to prevent



their transmission to their destination, but which were discarded (for example, for lack of



buffer space).



This counter would include datagrams counted in ipForwDatagrams if any such packets



met this (discretionary) discard criterion.





ipDefaultTTL

The default value inserted into the Time-To-Live (TTL) field of the IP header of datagrams



originated at this switch, whenever a TTL value is not supplied by the transport layer



protocol.





Route statistics

Command: /stats/l3/route













Route statistics:







ipRoutesCur:

7 ipRoutesHighWater:

7



ipRoutesMax:

4096









The following table describes the Route statistics:



Table 58 Route statistics











Statistics

Description









ipRoutesCur

The total number of outstanding routes in the route table.









ipRoutesMax

The maximum number of supported routes.









ipRoutesHighWater

The highest number of routes ever recorded in the route table.











ARP statistics

Command: /stats/l3/arp

ARP statistics:





arpEntriesCur:

2 arpEntriesHighWater:

4

Statistics Menu 73

Page 73
