Table 49 Interface statistics for port

Statistics	Description

MulticastPkts—IfHCOut	The total number of packets that higher-level protocols requested to be transmitted, and
	which were addressed to a multicast address at this sublayer, including those that were
	discarded or not sent.
	For a MAC layer protocol, this includes both group and functional addresses. This
	object is a 64-bit version of ifOutMulticastPkts.

Discards—IfHCOut	The number of outbound packets that were chosen to be discarded even though no
	errors had been detected to prevent their being transmitted. One possible reason for
	discarding such a packet could be to free up buffer space.

Errors—IfHCOut	For packet-oriented interfaces, the number of outbound packets that could not be
	transmitted because of errors.
	For character-oriented or fixed-length interfaces, the number of outbound transmission
	units that could not be transmitted because of errors.

Internet Protocol (IP) statistics

Command: /stats/port <port number>/ipGEA IP statistics for port 1:ipInReceives : 0ipInHeaderError: 0ipInDiscards : 0

The following table describes the Internet Protocol (IP) statistics for a selected port:

Table 50 IP statistics for port

Statistics	Description

ipInReceives	The total number of input datagrams received from interfaces, including those received in
	error.

ipInHeaderError	The number of input datagrams discarded because the IP address in their IP header's
	destination field was not a valid address to be received at this entity (the switch).

ipInDiscards	The number of input IP datagrams for which no problems were encountered to prevent their
	continued processing, but which were discarded (for example, for lack of buffer space). Note
	that this counter does not include any datagrams discarded while awaiting re-assembly.

Link statistics

Command: /stats/port <port number>/linkLink statistics for port 1:linkStateChange:2The following table describes the link statistics for a selected port:Table 51 Link statistics for port

Statistic	Description

linkStateChange	The total number of link state changes.

Statistics Menu 68
