virtual router ID and an IP address. On each VRRP-capable routing device participating in redundancy for this virtual router, a virtual router will be configured to share the same virtual router ID and IP address.

The following table describes the Virtual Router Group Configuration Menu options.

Table 153 Virtual Router Group Configuration Menu options

Command

Description





track

Displays the VRRP Priority Tracking Menu for the virtual router group. Tracking



is a proprietary extension to VRRP, used for modifying the standard priority



system used for electing the master router.





vrid <1-255>

Defines the virtual router ID.



The vrid for standard virtual routers (where the virtual router IP address is not



the same as any virtual server) can be any integer between 1 and 255. All



vrid values must be unique within the VLAN to which the virtual router’s IP



interface (see if below) belongs. The default virtual router ID is 1.





if <1-256>

Selects a switch IP interface. The default switch IP interface number is 1.





prio <1-254>

Defines the election priority bias for this virtual router group. This can be any



integer between 1 and 254. The default value is 100.



During the master router election process, the routing device with the highest



virtual router priority number wins. If there is a tie, the device with the highest IP



interface address wins. If this virtual router’s IP address (addr) is the same as



the one used by the IP interface, the priority for this virtual router will



automatically be set to 255 (highest).



When priority tracking is used (/cfg/l3/vrrp/track or



/cfg/l3/vrrp/vr #/track), this base priority value can be modified



according to a number of performance and operational criteria.





adver <1-255>

Defines the time interval between VRRP master advertisements. This can be any



integer between 1 and 255 seconds. The default is 1.





preem disableenable

Enables or disables master preemption. When enabled, if the virtual router



group is in backup mode but has a higher priority than the current master, this



virtual router will preempt the lower priority master and assume control. Note



that even when preem is disabled, this virtual router will always preempt any



other master if this switch is the owner (the IP interface address and virtual



router addr are the same). By default, this option is enabled.





ena

Enables the virtual router group.





dis

Disables the virtual router group.





del

Deletes the virtual router group from the switch configuration.





cur

Displays the current configuration information for the virtual router group.





VRRP Virtual Router Group Priority Tracking configuration

Command: /cfg/l3/vrrp/group/track



[Virtual Router

Group Priority Tracking Menu]



ifs

-

Enable/disable tracking

other interfaces



ports

-

Enable/disable tracking

VLAN switch ports



cur

-

Display current VRRP Group Tracking configuration

























NOTE: If Virtual Router Group Tracking is enabled, then the tracking option will be available only under group option. The tracking setting for the other individual virtual routers will be ignored.
