Table 48 Ethernet statistics for port

StatisticsDescription

dot3StatsInternalMacReceiveErrors A count of frames for which reception on a particular interface fails due to an internal MAC sublayer receive error.

A frame is only counted by an instance of this object if it is not counted by the corresponding instance of the dot3StatsFrameTooLongs object, the dot3StatsAlignmentErrors object, or the dot3StatsFCSErrors object.

The precise meaning of the count represented by an instance of this object is implementation specific. In particular, an instance of this object may represent a count of received errors on a particular interface that are not otherwise counted.

Interface statistics

Command: /stats/port <port number>/if



Interface statistics for port 1:









ifHCIn Counters

ifHCOut Counters





Octets:

51697080313

51721056808





UcastPkts:

65356399

65385714





BroadcastPkts:

0

6516





MulticastPkts:

0

0





Discards:

0

0





Errors:

0

21187









The following table describes the interface (IF) statistics for a selected port:



Table 49 Interface statistics for port













Statistics

Description











Octets—IfHCIn

The total number of octets received on the interface, including framing characters.









UcastPkts—IfHCIn

The number of packets, delivered by this sublayer to a higher sublayer, which were not







addressed to a multicast or broadcast address at this sublayer.









BroadcastPkts—IfHCIn

The number of packets, delivered by this sublayer to a higher sublayer, which were







addressed to a broadcast address at this sublayer.









MulticastPkts—IfHCIn

The total number of packets, delivered by this sublayer. These are the packets that







higher-level protocols requested to be transmitted, and which were addressed to a







multicast address at this sublayer, including those that were discarded or not sent.







For a MAC layer protocol, this includes both group and functional addresses.









Discards—IfHCIn

The number of inbound packets which were chosen to be discarded even though no







errors were detected to prevent their being delivered to a higher-layer protocol. One







possible reason for discarding such a packet could be to free up buffer space.









Errors—IfHCIn

For packet-oriented interfaces, the number of inbound packets that contained errors







preventing them from being delivered to a higher-layer protocol.







For character-oriented or fixed-length interfaces, the number of inbound transmission







units that contained errors preventing them from being deliverable to a higher-layer







protocol.











Octets—IfHCOut

The total number of octets transmitted out of the interface, including framing characters.









UcastPkts—IfHCOut

The total number of packets that higher-level protocols requested to be transmitted, and







which were not addressed to a multicast or broadcast address at this sublayer,







including those that were discarded or not sent.









BroadcastPkts—IfHCOut

The total number of packets that higher-level protocols requested to be transmitted, and







which were addressed to a broadcast address at this sublayer, including those that







were discarded or not sent. This object is a 64-bit version of ifOutBroadcastPkts.













Statistics Menu 67
