HP GbE2c 170

IGMP Snooping options

Command: /maint/igmp/snoop

[IGMP Multicast		Group Menu]
find	-	Show a single group by IP group address
vlan	-	Show groups on a single vlan
port	-	Show groups on a single port
trunk	-	Show groups on a single trunk
dump	-	Show all groups
clear	-	Clear group tables

The following table describes the IGMP Snoop Maintenance Menu options.

Table 192 IGMP Snooping Menu options

Command	Usage

find <IP address>	Shows a single IGMP Multicast group by IP address.

vlan <1-4094>	Shows IGMP Multicast groups on a single VLAN.

port <port number>	Shows IGMP Multicast groups on a single port.

dump	Shows all IGMP Multicast groups.

clear	Clears IGMP Multicast data from switch memory.

IGMP Mrouter options

Command: /maint/igmp/mrouter

[IGMP Multicast		Routers Menu]
vlan	-	Show	all	multicast router ports on a single vlan
dump	-	Show	all	multicast router ports
clear	-	Clear multicast router port table

The following table describes the IGMP Multicast Routers Maintenance Menu options.

Table 193 IGMP Multicast Group Menu options

Command	Usage

vlan <1-4094>	Shows IGMP Multicast groups on a single VLAN.

dump	Shows all IGMP Multicast routers.

clear	Clears IGMP Multicast router data from switch memory.

Maintenance Menu 170
