Operations Menu

Introduction

Operations-level commands are used for making immediate and temporary changes to switch configuration. The Operations Menu is used for bringing ports temporarily in and out of service. This menu is available only from an administrator and operator login.

Menu information

Command: /oper[Operations Menu]

port	- Operational Port Menu
vrrp	- Operational Virtual Router Redundancy Menu
passwd	- Change current user password
clrlog	-	Clear syslog messages
ntpreq	-	Send NTP request

The following table describes the Operations Menu options.Table 181 Operations Menu options

Command	Description

port <port number>	Displays the Operational Port Menu.

*vrrp	Displays the Operational Virtual Router Redundancy Menu. VRRP is available only on
	the GbE2c Layer 2/3 Ethernet Blade Switch.

passwd <1-128	Allows the user to change the password. You need to enter the current password in
characters>	use for validation.

clrlog	Clears all Syslog messages.

ntpreq	Allows the user to send requests to the NTP server.

Operations-level port options

Command: /oper/port <port number>[Operations Port 1 Menu]

8021x	- 8021.x Menu
rmon	- Enable/Disable RMON for port
ena	- Enable port
dis	-	Disable port
cur	-	Current port state

Operations-level port options are used for temporarily disabling or enabling a port.

Table 182 Operations-Level Port Menu optionsCommandDescription

8021x

Displays the 802.1x Port Menu.

rmon disableenable Enables or disables Remote Monitoring for the port. RMON must be enabled for any RMON configurations to function.

ena	Temporarily enables the port. The port will be returned to its configured operation mode
	when the switch is reset.

NOTE:	This command does not enable a port that has been disabled by an ekeying mismatch error.

dis	Temporarily disables the port. The port will be returned to its configured operation mode
	when the switch is reset.

cur	Displays the current settings for the port.

	Operations Menu 160
