LACP statisticsCommand: /stats/l2/lacp <port number>

Valid LACPDUs received	- 0
Valid Marker PDUs received	- 0
Valid Marker Rsp PDUs received - 0
Unknown version/TLV type	- 0
Illegal subtype received	- 0
LACPDUs transmitted	- 0
Marker PDUs transmitted	- 0
Marker Rsp PDUs transmitted	- 0

Layer 3 statisticsCommand: /stats/l3[Layer 3 Statistics Menu]

geal3	- GEA Layer 3 Stats Menu
ip	- Show IP stats
route	- Show route stats
arp	- Show ARP stats
dns	- Show DNS stats
icmp	- Show ICMP stats
tcp	- Show TCP stats
udp	- Show UDP stats
igmp	- Show IGMP stats
ospf	- OSPF stats
vrrp	- Show VRRP stats
rip	- Show RIP stats
clrigmp	- Clear IGMP stats
ipclear	- Clear IP stats
dump	- Dump layer 3 stats

The following table describes the Layer 3 Statistics Menu options.Table 55 Layer 3 Statistics Menu options

Command	Usage

geal3	Displays the GEA statistics menu.

ip	Displays IP statistics.

route	Displays route statistics.

arp <clear>	Displays Address Resolution Protocol (ARP) statistics. Add the
	argument, clear, to clear ARP statistics.

dns	Displays Domain Name System (DNS) statistics.

icmp	Displays ICMP statistics.

tcp	Displays Transmission Control Protocol (TCP) statistics. Add the
	argument, clear, to clear TCP statistics.

udp	Displays User Datagram Protocol (UDP) statistics. Add the argument,
	clear, to clear UDP statistics.

igmp	Displays IGMP statistics.

*ospf	Displays OSPF statistics menu.

*vrrp	When virtual routers are configured, you can display the following
	•	Advertisements received (vrrpInAdvers)
	•	Advertisements transmitted (vrrpOutAdvers)
	• Advertisements received, but ignored (vrrpBadAdvers)

*rip	Displays Routing Information Protocol (RIP) statistics

clrigmp <1-4095>all	Clears all IGMP statistics for the selected VLANs.

Statistics Menu 71
