Table 67 VRRP statistics

Field	Description

vrrpBadInterval	The total number of VRRP advertisements that had a bad interval.

RIP statistics

NOTE: RIP commands are available only on the GbE2c Layer 2/3 Ethernet Blade Switch.

Command:		/stats/l3/rip

	RIP ALL STATS INFORMATION:
		RIP packets received = 12
		RIP packets sent = 75
		RIP request received = 0
		RIP response received = 12
		RIP request sent = 3
		RIP response sent = 72
		RIP route timeout = 0
		RIP bad		size packet received = 0
		RIP bad		version received = 0
		RIP bad		zeros received = 0
		RIP bad		src port received = 0
		RIP bad		src IP received = 0
		RIP packets from self received = 0
Management Processor statistics
Command:		/stats/mp

	[MP-specific Statistics Menu]
		pkt	-	Show Packet stats
		tcb	-	Show All TCP control blocks in use
		ucb	-	Show All UDP control blocks in use
		cpu	-	Show CPU utilization

The following table describes the Statistics Menu options for the management processor (MP):

Table 68 MP-specific Statistics Menu

Command	Usage

pkt	Displays packet statistics, to check for leads and load.

tcb	Displays all Transmission Control Protocol (TCP) control blocks (TCB) that are in use.

ucb	Displays all User Datagram Protocol (UDP) control blocks (UCB) that are in use.

cpu	Displays CPU utilization for periods of up to 1, 4, and 64 seconds.

Packet statistics

Command: /stats/mp/pkt

Packet counts:
allocs:	36692	frees:	36692
mediums:	0	mediums hi-watermark:	3
jumbos:	0	jumbos hi-watermark:	0
smalls:	0	smalls hi-watermark:	2
failures:	0

Statistics Menu 81
