The rmap number (1-32) and the path number (1-8) represent the AS path you wish to configure. The following table describes the Autonomous System Path Configuration Menu options.

Table 130 Autonomous System Path Configuration Menu options

Command	Description

as <1-65535>	Sets the Autonomous System filter’s path number.

action permitdeny	Permits or denies Autonomous System filter action.

enable	Enables the Autonomous System filter.

disable	Disables the Autonomous System filter.

delete	Deletes the Autonomous System filter.

cur	Displays the current Autonomous System filter configuration.

Routing Information Protocol configurationCommand: /cfg/l3/rip

	[Routing Information Protocol		Menu]
	if	- RIP Interface	Menu
	update	- Set update period in seconds
	redist	- RIP Route Redistribute Menu
	on	- Globally turn	RIP ON
	off	- Globally turn	RIP OFF
	current	- Display current RIP configuration

NOTE: This menu is available only on the GbE2c Layer 2/3 Ethernet Blade Switch.

The RIP Menu is used for configuring Routing Information Protocol parameters. This option is turned off by default. The following table describes the RIP Configuration Menu options.

Table 131 RIP Configuration Menu options

Command	Description

if <1-256>	Displays the RIP Interface menu.

update <1-120>	Configures the time interval for sending for RIP table updates, in seconds.
	The default value is 30 seconds.

redist	Displays the RIP Route Redistribute menu.

on	Globally turns RIP on.

off	Globally turns RIP off.

cur	Displays the current RIP configuration.

Configuration Menu 128
