HP GbE2c 120

IP Trunk Hash configuration

Command: /cfg/l2/thash

[IP Trunk Hash Menu]

set	-	IP Trunk Hash Settings Menu
cur	-	Display current IP trunk hash configuration

The following table describes the IP Trunk Hash Configuration Menu options.

Table 116 IP Trunk Hash Configuration Menu options

Command	Description

set	Displays the Trunk Hash Settings menu.

cur	Display current trunk hash configuration.

Layer 2 IP Trunk Hash configuration

Command: /cfg/l2/thash/set

[set IP Trunk	Hash Settings Menu]
smac	- Enable/disable smac hash
dmac	- Enable/disable dmac hash
sip	- Enable/disable sip hash
dip	- Enable/disable dip hash
cur	- Display current trunk hash setting

Trunk hash parameters are set globally for the GbE2c. You can enable one or two parameters, to configure any of the following valid combinations:

•SMAC (source MAC only)

•DMAC (destination MAC only)

•SIP (source IP only)

•DIP (destination IP only)

•SIP + DIP (source IP and destination IP)

•SMAC + DMAC (source MAC and destination MAC)

The following table describes the IP Trunk Hash Configuration Menu options.

Table 117 IP Trunk Hash Set Menu options

Command	Description

smac enabledisable	Enable or disable trunk hashing on the source MAC.

dmac enabledisable	Enable or disable trunk hashing on the destination MAC.

sip enabledisable	Enable or disable trunk hashing on the source IP.

dip enabledisable	Enable or disable trunk hashing on the destination IP.

cur	Display current trunk hash configuration.

Link Aggregation Control Protocol configuration

Command: /cfg/l2/lacp

[LACP Menu]
sysprio	- Set LACP system priority
timeout	- Set LACP system timeout scale for timing out partner info
port	-	LACP port Menu
cur	-	Display current LACP configuration
