OSPF global statistics

NOTE: OSPF commands are available only on the GbE2c Layer 2/3 Ethernet Blade Switch.

Command: /stats/l3/ospf/general

OSPF stats
----------
Rx/Tx Stats:	Rx	Tx
	--------	--------
Pkts	0	0
hello	23	518
database	4	12
ls requests	3	1
ls acks	7	7
ls updates	9	7
Nbr change stats:		Intf change Stats:
hello	2	up	4
start	0	down 2
n2way	2	loop 0
adjoint ok	2	unloop 0
negotiation done	2	wait timer 2
exchange done	2	backup 0
bad requests	0	nbr change 5
bad sequence	0
loading done	2
n1way	0
rst_ad	0
down	1
Timers kickoff
hello	514
retransmit	1028
lsa lock	0
lsa ack	0
dbage	0
summary	0
ase export	0

The following table describes the OSPF global statistics:Table 66 OSPF global statistics

StatisticDescription

Rx Tx stats:

Rx Pkts	The sum total of all OSPF packets received on all OSPF areas and interfaces.

Tx Pkts	The sum total of all OSPF packets transmitted on all OSPF areas and interfaces.

Rx Hello	The sum total of all Hello packets received on all OSPF areas and interfaces.

Tx Hello	The sum total of all Hello packets transmitted on all OSPF areas and interfaces.

Rx Database	The sum total of all Database Description packets received on all OSPF areas and
	interfaces.

Tx Database	The sum total of all Database Description packets transmitted on all OSPF areas and
	interfaces.

Rx ls Requests	The sum total of all Link State Request packets received on all OSPF
	areas and interfaces.

Tx ls Requests	The sum total of all Link State Request packets transmitted on all OSPF areas and
	interfaces.

Rx ls Acks	The sum total of all Link State Acknowledgement packets received on all OSPF areas
	and interfaces.

Tx ls Acks	The sum total of all Link State Acknowledgement packets transmitted on all OSPF
	areas and interfaces.

Rx ls Updates	The sum total of all Link State Update packets received on all OSPF areas and
	interfaces.

	Statistics Menu 78
