RIP user configuration

NOTE: RIP commands are available only on the GbE2c Layer 2/3 Ethernet Blade Switch.

Command: /info/l3/rip/dump <1-255>

RIP USER CONFIGURATION : RIP on updat 30

RIP Interface 2 : 102.1.1.1, enabled

version 2, listen enabled, supply enabled, default none poison disabled, trigg enabled, mcast enabled, metric 1 auth none,key none

RIP Interface 3 : 103.1.1.1, enabled

version 2, listen enabled, supply enabled, default none poison disabled, trigg enabled, mcast enabled, metric 1

IP information

Command: /info/l3/ip

Interface information:
1: 47.80.23.243	255.255.254.0	47.80.23.255,	up
Default gateway information:
1: 47.80.22.1,	up
2: 47.80.225.2,	up

Current BOOTP relay settings: OFF

0.0.0.0, 0.0.0.0

Current IP forwarding settings: OFF, dirbr disabled

Current network filter settings:

none

Current route map settings:

The following interface and default gateway information is displayed (some fields apply only to the GbE2c Layer 2/3 Ethernet Blade Switch):

•Interface number

•IP address

•IP mask

•IP broadcast address

•Operational status

•BootP relay settings

•IP forwarding settings

•Network filter settings

•Route map settings

IGMP multicast group information

Command: /info/l3/igmp

[IGMP Multicast		Group Menu]
mrouter	-	Show IGMP Snooping Multicast Router Port information
find	-	Show a single group by IP group address
vlan	-	Show groups on a single vlan
port	-	Show groups on a single port
trunk	-	Show groups on a single trunk
dump	-	Show all groups

The following table describes the commands used to display information about IGMP groups learned by the switch.

Table 35 IGMP Multicast Group menu options

Information Menu 51
