The following table describes the LACP Configuration Menu options.

Table 118 LACP Configuration Menu options

Command

Description





sysprio <1-65535>

Defines the priority value (1 through 65535) for the switch. Lower



numbers provide higher priority. The default value is 32768.





timeout shortlong

Defines the timeout period before invalidating LACP data from a remote



partner. Choose short (3 seconds) or long (90 seconds). The default



value is long.



Note: HP recommends that you use a timeout value of long, to reduce



LACPDU processing. If your switch’s CPU utilization rate remains at 100%



for periods of 90 seconds or more, consider using static trunks instead of



LACP.





port <port number>

Displays the LACP Port menu.





cur

Display current LACP configuration.





LACP Port configuration

Command: /cfg/l2/lacp/port <port number>

[LACP Port 2 Menu]

mode

- Set LACP mode

prio

- Set LACP port priority

adminkey

-

Set LACP port admin key

cur

-

Display current LACP port configuration

The following table describes the LACP Port Configuration Menu options.

Table 119 LACP Port Configuration Menu options

Command

Description





mode offactivepassive

Set the LACP mode for this port, as follows:



off





Turn LACP off for this port. You can use this port to manually configure a



static trunk. The default value is off.



active



Turn LACP on and set this port to active. Active ports initiate LACPDUs.



passive





Turn LACP on and set this port to passive. Passive ports do not initiate





LACPDUs, but respond to LACPDUs from active ports.





prio <1-65535>

Sets the priority value for the selected port. Lower numbers provide higher



priority. Default is 128.





adminkey <1-65535>

Set the admin key for this port. Only ports with the same admin key and oper



key (operational state generated internally) can form a LACP trunk group.





cur

Displays the current LACP configuration for this port.







VLAN configuration

Command: /cfg/l2/vlan <1-4095>

[VLAN 1 Menu]





name

- Set VLAN name



stg

- Assign VLAN to a Spanning Tree Group



add

- Add port to VLAN



rem

- Remove port from VLAN



def

- Define VLAN as list of ports



ena

- Enable VLAN



dis

- Disable VLAN



del

- Delete VLAN



cur

- Display current VLAN configuration











Configuration Menu 121

Page 121
