3Withdraw the module from the drive bay and fit a replacement module in accordance with the instructions in Section 2.9.

4.10Spare Parts and Ancillary Items

The following replaceable parts are available for the DCS9550 1S1 Storage Expansion Unit:

IBM MTM 1269-1S1 SATA Disk Chassis FRUs

IBM Part
Number	Description
95P5297	1269-1S1 SATA disk chassis assembly FRU without drives
95P5313	power supply/fan FRU
95P5315	SCM I/O Module FRU
95P5316	Op panel FRU
95P5317	drive module key
95P5318	power cord FRU
95P5319	cable RS232 config FRU
95P5320	rail kit FRU
95P5326	250GB SATA HDD FRU for FC 3010
95P5327	500GB SATA HDD FRU for FC 3012
95P5325	Drive Filler FRU
95P7184	Blank SCM module filler

IBM System Storage DCS9550 1S1 Storage Expansion Unit Installation, Service, and User Guide
