JVC GV-DS2 manual To print only the cut-in scene on the edited tape

Auto-Capture

Image has been captured by printer.

PRINT NEXT SCENE… CANCEL

EN 63

3 Click the Title bar in the JLIP VIDEO PRODUCER window and activate the window.

4 Select "Set-up" — "Function Set" — "Auto Capture".

5 Click "START"

•The captured video data set first is searched and stored in the video printer.

•When the data has been stored, the message "Image has been captured by printer." appears.

•If the number of scenes was set to "OFF", or "4 or 16" in step 2 and then to "SAME", you can start printing simply by clicking "PRINT".

•If the number of scenes was set to "4 or 16" in step 2 and then to "SELECTED", click "NEXT SCENE". The next scene is automatically searched and stored in the video printer.

6 Click "PRINT" to start printing.

NOTES:

To print only the cut-in scene on the edited tape

1 Perform editing (refer to pages 50 through

52).

2Print (follow steps 1 through 5 above).

●Select "Auto Capture" in step 4.

●Click "START" in step 5. The cut-in point of Scene No. 1 is automatically searched and stored in the video printer.

●You cannot start storing from Scene No. 2 or subsequent scenes.

●Even if the video unit is in Stop mode, clicking "START" automatically starts playback to search the cut-in point of Scene No. 1.

●If you want to print a particular scene only, click "SCENE" in step 5.
