Page 66

66 EN

Modify

Information

POWER

	NAVI	HDD	PLAY		VHS
POWER				S		EJECT
				-
				DIGITPURE TECHNOLOGY

HM-HDS1

REC LINK		STOP	PLAY	PAUSE	REC	S-VHS ET
	HDD					S-VHS		VIDEO	(M) L – AUDIO – R
MENU	NAVI					REW	FEW
OK								FF	S-VIDEO
	CH					A. DUB		FF	PAUSE
								- 1

OK	STOP	PAUSE	REW
OK

VHS

POWER

2

3

4

5

EDITING (cont.)

SELECT DECK

Press HDD or VHS (or S-VHS).

●When you select the VHS deck, load the cassette you want to edit.

ACCESS NAVIGATION SCREEN

Press NAVI. The Navigation screen corresponding to the selected deck appears.

●For VHS deck, when “NAVIGATION” is set to “OFF”, the Navigation screen does not appear.

SELECT PROGRAM

Press @%#ﬁ (or 253∞) to move the arrow to select one program you want to modify, then press ﬁ (or ∞) or OK.

ACCESS MODIFY SCREEN

1)Press @# (or 23) to move the arrow to “MODIFY”, then press ﬁ (or ∞) or OK.

2)Press @# (or 23) to move the arrow to “MODIFY INDEX”, then press OK. The arrow moves to “REPLACE”.

HDD 1

2
1	2	3
4	5	6
7	8	9
<	0	>
1
2
LAY

REW

OK/STOP

– +

NAVI

3

4

	OK
FF	PAUSE
	PAUSE

6

7

REGISTER NEW INDEX

1) Search for the picture

from the program by

HDD NAVI

MODIFY INDEX

MODIFY TITLE MODIFY CATEGORY

pressing the appropri-

ate buttons: PLAY, FF,

REPLACE

REW, or PAUSE. The

START 0:10:30 END

0:10:30

pictures of the

[MISC.]

program appear on

06/12/01 TUE 12:25AM – 12:55PM 2CH

SP 30min

RETURN

the left window.

INDEX

NAVI

SELECT WITH [∞523]

2) Confirm the arrow is

SELECT OK

END THEN PRESS

[OK]

on “REPLACE”, then

press OK to register new index. New index appears on the right window.

●When you press OK with the arrow on “RETURN” you can return the previous screen.

RETURN TO NORMAL SCREEN

Press NAVI.

●When you select VHS deck, press STOP to cancel PAUSE after pressing NAVI.

Modify Index

The Navigation systems cannot work while the recorder is recording on the HDD deck or in REC LINK mode.

TURN ON THE RECORDER

1 Press POWER.
