10.9.3. Key lock function setting items
Set the keys to be locked on the key lock function setting screen. The KEYLOCK indication lights after setting completion. Since a password is requested if the locked key is pressed, enter the password.
Unless otherwise specified, use the Parameter setting knob for each parameter selection.
(G1)
K E Y L O C K A L L O F F
Selecting ON locks all keys located on the front panel.
If ON/OFF settings differ from key to key, the [- -
(G2) Input key lock ON/OFF
K E Y L O C K I N P U T O F F
Locks all Input channel selection keys, Input channel ON/OFF key, and Input volume control.
If ON/OFF settings differ from channel to channel, the [- -
(G3) Input channel selection key lock ON/OFF
K E Y L O C K I N C H 1 O F F
Locks the Input channel selection key, Input channel ON/OFF key, and Input volume control for each input channel.
Select with the Parameter setting knob the input channel to be locked, and set the key lock function to ON with the Input channel ON/OFF key.
(G4) Output key lock ON/OFF
K E Y L O C K O U T P U T O F F
Locks all Output channel selection keys, Output channel ON/OFF key, and Output volume control.
If ON/OFF settings differ from channel to channel, the [- -
(G5) Output channel selection key lock ON/OFF
K E Y L O C K O U T C H 1 O F F
Locks the Output channel selection key, Output channel ON/OFF key, and Output volume control for each Output channel.
Select with the Parameter setting knob the Output channel to be locked, and set the key lock function to ON with the Output channel ON/OFF key.
The Output channel selection key selects an output channel one by one only in numerical order starting from Channel 1. So, when the output channel selection key is locked at an output channel, the subsequent output channels cannot be used unless the locked key is unlocked at the channel by entering a password.
