5.4 ALARM SETTING

This menu allows users to program the configuration of alarm recording only when an alarm input is activated. The device will record as long as the alarm input is activated.

MAIN MENU

TIME/ TITLE

RECORD TIMER

RECORD

ALARM

COMMUNICATION

DISK

SYSTEM

GO TO ALARM PAGE

ALM OPERATION:

ALARM SETTING

ALM OPERATION



: OFF

REC RATE



: 60 F/S

REC QUALITY

: HIGH

ALM TYPE

: NO

ALM DURATION

: NON STOP

PRE-ALARM

: OFF

MAIN PAGE



ALARM REC ENABLE

The ALM OPERATION option is used to determine whether to activate/deactivate the alarm recording when it detects an alarm input.

ON: The device activates the alarm recording when it detects an alarm input. OFF: The device ignores the alarm signal when it detects an alarm input.

REC RATE:

The REC RATE option is used for adjusting the number of pictures recorded every second into a hard disk when an alarm input is activated. For a NTSC unit, there are 5 different record speeds you can select from: 60F/S (60 fields per second), 20F/S, 10F/S, 5F/S, and REMAIN. And for a PAL unit, there are 5 different record speeds you can select from: 50F/S (50 fields per second), 25F/S, 10F/S, 6.25F/S and REMAIN. If you select REMAIN for use, the device will record images at the same speed as set on the REC page.

REC QUALITY:

The REC QUALITY option is used to determine the quality of the image being recorded. There are 3 levels of image quality you can select from HIGH, STANDARD, and BASIC. Selecting HIGH image quality will result in higher-resolution recorded images, and will normally take up more storage space than a STANDARD or BASIC quality image does. The table below shows the level of image quality with the corresponding compression ratio and image size.
