Maytag W10201177B manual Reverse Door Swing, Remove the door assembly, Reverse the strike

If the dryer is not level, prop up the dryer using a wood block. Use a wrench to adjust the legs up or down and check again for levelness.

Reverse Door Swing

You can change your door swing from a right-side opening to a left-side opening, if desired.

1.Place a towel or soft cloth on top of the dryer or work space to avoid damaging the surface.

Remove the door assembly

1.Open the dryer door.

2.Remove the bottom screw from each of the 2 hinges that attach the dryer door to the front panel of the dryer.

3.Loosen the top screw from each of the 2 hinges in Step 2.

A

B

A

B

5.Remove the 4 plastic plugs located outside the dryer door opening.

Location of plastic plugs shown

6.Install 4 plastic plugs into screw holes in the dryer left where the hinges were removed in Step 4.

Reverse the strike

1.Remove the door strike from the dryer door opening.

2.Remove the cosmetic cover opposite the door strike.

A B

A. Loosen these screws.

B. Remove these screws.

4.Remove the dryer door and the hinges by lifting upward on the door. Lay the door on a flat, protected surface, with the inside of the door facing up. Remove remaining 2 loose screws from dryer front panel.

A. Door strike

B. Cosmetic cover

3.Reinstall the door strike and cosmetic cover on the opposite side of the dryer door opening from where they were removed.

NOTE: Door strike and plugs must be on the same side of the dryer door opening.

14
