1 A/D Converter, Table A-2 Converter Specifications | Digi RCM4000

A.1.1 A/D Converter

Table A-2shows some of the important A/D converter specifications. For more details, refer to the ADC7870 data sheet.

Table A-2.		A/D Converter Specifications

Parameter		Test Conditions	Typ	Max

Analog Input Characteristics
Input Capacitance			4 – 9.7 pF
Input Impedance
Common-Mode			6 MΩ
Differential Mode			7 MΩ

Static Accuracy
Resolution
Single-Ended Mode			11 bits
Differential Mode			12 bits
Integral Linearity			±1 LSB	±2.5 LSB
Differential Linearity			±0.5 LSB

Dynamic Characteristics
Throughput Rate			52 ksamples/s

Voltage Reference
Accuracy		Vref = 2.048 V and 2.5 V	±0.05%	±0.25%
Buffer Amp Source Current			20 µA
Buffer Amp Sink Current			20 mA
Short-Circuit Current			20 mA

82	RabbitCore RCM4000
