3: Command Line Interface

An overview of the levels in the PremierWave XN is presented in Figure 3-2 CLI Level Hierarchy below.

Figure 3-2 CLI Level Hierarchy

(login)

enable	configure
	device
	dns
	email <number>
	filesystem
	line <line>
	ssh	client
		server
	ssl	credentials
		trusted authorities
	tunnel <line>	accept
		connect
		disconnect
		modem
		packing
		serial
	xml

arp

bridge <bridge>

cli

diagnostics

ftp

host <number>

http

icmp

if 1

if 2

ip

query port

rss

smtp

syslog

terminal <line>

terminal network

vip

wlan profiles

ssh

telnet

log

ethernet link

wlan link

edit <name>

Commands at the login level (see Figure 3-3 Login Level Commands below) do not affect current configuration settings and are not displayed initially. If you type ?, you will see the login sub- commands. These commands provide diagnostic and status information only.

	Figure 3-3 Login Level Commands
>?
clrscrn		exit
ping <host>		ping <host> <count>
ping <host>	<count> <timeout>	show
show history		trace route <host>
trace route	<host> <protocol>	enable
>

Note: To configure the PremierWave XN, you must be in the enable level and any of its sub-levels. Figure 3-4below shows the enable level commands.
