Chapter 3. Performance

■Producing the Resonance of the Strings When

the Keys Are Played (Damper Resonance)

You can change the volume of the damper pedal resonance.

On an acoustic piano, depressing the damper pedal makes the notes you play resonate with other strings, adding rich reverberations and fatness to the sound. The damper pedal on the RG-7 recreates this resonance (Damper Resonance) when depressed.

1 Press the [Function] (Exit) button, getting its indicator to light.

2 Press the [Song] (Select -) button or [ ] (Select +) button to display the RESONANCE screen.

fig.

3 Press the [Song] (Select -) button or [ ] (Select +) button to get the value for “Damper” to flash.

fig.

4	Press the [	] (Value -) or [		] (Value +) button to change the value.
	Value			Description
			The resonance volume decreases as the value is lowered,
	0–9		while raising the value increases the volume of the
			Damper Resonance.
			The Damper Resonance function is not active when the
			value is set to “0.”
5
	Press the [Function] (Exit) button so the indicator goes out.

NOTE

This setting is enabled only with the piano tones. You cannot set this for other tones.

You can save this setting in the RG-7’s memory using the Memory Backup function (p. 72).

59
