Boot Sequence | The computer attempts to boot from the sequence of devices specified in |
| this list. |
| NOTE: If you insert a boot device and restart the computer, this option |
| appears in the system setup menu. To boot from a USB memory device, select |
| the USB device and move it so it becomes the first device in the list. |
|
|
Drives |
|
|
|
Diskette Drive | Identifies and defines the floppy drive attached to the FLOPPY connector |
| on the system board as Off, USB, Internal, or Read Only. |
|
|
Drives 0 through 1 | Identifies the drives attached to the SATA connectors on the system board, |
| and lists the capacity for hard drives. |
|
|
Onboard Devices |
|
|
|
Integrated NIC | You can set the NIC to On (default), Off, or On w/ PXE. When the On w/ |
Controller | PXE setting is active (available only for the future boot process), the |
| computer prompts you to press <Ctrl><Alt><b>. Pressing this key |
| combination causes a menu to display that allows you to select a method |
| for booting from a network server. If a boot routine is not available from the |
| network server, the computer attempts to boot from the next device in the |
| boot sequence list. |
|
|
Integrated Audio | Enables or disables the onboard audio controller. |
Controller |
|
|
|
USB Controller | Set to On (default) so that USB devices will be detected and supported in |
| the operating system. |
|
|
USB for FlexBay | This field enables and disables the internal USB for FlexBay. |
| Off = Internal USB for FlexBay is disabled. |
| On = Internal USB for FlexBay is enabled. |
| The factory default setting is On. |
| NOTE: This USB option appears only if a FlexBay device is installed. |
|
|
Video |
|
|
|
Primary Video | This setting specifies which video controller is primary when two video |
| controllers are present on the computer. |
|
|
Video Memory Size | Offering selectable options of 1MB and 8MB, this field configures the |
| system memory allocation reserved for the integrated video controller. |
