Usb | Dell E02B specs

Drives

Flash drive	Internal optional USB
	Internal optional SD card
	Optional vFlash card (with integrated iDRAC8
	Enterprise)

Connectors

Front

USB

Internal

SD

One 4-pin, USB 2.0-compliant and one 4-pin, USB 3.0-compliant

Two internal SD cards dedicated for the hypervisor

One SD card dedicated for future vFlash support

PCIe mezzanine card

PCIe mezzanine card slots	One PCIe x16 Gen 3 slot that supports PCIe
	mezzanine card

Video

Video type	Matrox G200 VGA controller integrated with
	iDRAC
Video memory	2 GB shared with iDRAC application memory

Battery

NVRAM backup battery	CR 2032 3.0 V lithium coin cell

Environmental specifications

NOTE: For additional information about environmental measurements for specific system configurations, see dell.com/environmental_datasheets.

Temperature
Storage	–40°C to 65°C (–40°F to 149°F)
Continuous operation (for altitude less than 950	10°C to 35°C (50°F to 95°F) with no direct
m or 3117 ft)	sunlight on the equipment.
Fresh air	For information on fresh air, see Expanded
	Operating Temperature section.
Maximum temperature gradient (operating and	20°C/h (36°F/h)
storage)

108

Image 108
