Table
Input source | PCL 5 | PCL 6 | PCL 6 | PostScript |
| Esc&l#H | ubyte # | ubyte_array | /MediaPosition |
|
| MediaSource 2 | "string" | # or null/ |
|
|
| MediaSource | ManualFeed true |
|
|
|
| or false |
Envelope feeder 1 | 6 |
| ENVELOPETRAY | 2 false |
1Trays 4 through 9 and the envelope feeder are not options for the HP Color LaserJet Enterprise
2For the string value, you must include the quotation marks around the variable. For example, ubyte_array "TRAY2" MediaSource is the PCL 6 command for Tray 2.
3Refers to optional trays.
The PCL 5 print driver escape sequence for paper type is "Esc&n#Wdpapertype", where "n#" is the number of characters in the paper type plus 1. For example, in the sequence "Esc&n6WdPlain", "Plain" has 5 letters plus 1, for a total of 6.
Table
Esc& | n# | Wd | Paper type |
|
|
|
|
Esc& | 6 | Wd | Plain |
|
|
|
|
Esc& | 11 | Wd | Preprinted |
|
|
|
|
Esc& | 11 | Wd | Letterhead |
|
|
|
|
Esc& | 13 | Wd | Transparency1 |
|
|
|
|
Esc& | 11 | Wd | Prepunched |
|
|
|
|
Esc& | 7 | Wd | Labels |
|
|
|
|
Esc& | 5 | Wd | Bond |
|
|
|
|
Esc& | 9 | Wd | Recycled |
|
|
|
|
Esc& | 6 | Wd | Color |
|
|
|
|
Esc& | 6 | Wd | Light |
|
|
|
|
Esc& | 13 | Wd | Interpaperte |
|
|
|
|
Esc& | 6 | Wd | Heavy |
|
|
|
|
Esc& | 12 | Wd | Extra Heavy |
|
|
|
|
Esc& | 11 | Wd | Cardstock2 |
|
|
|
|
Esc& | 6 | Wd | Rough |
|
|
|
|
Esc& | 7 | Wd | Glossy |
|
|
|
|
Esc& | 12 | Wd | Tough Paper |
|
|
|
|
Esc& | 9 | Wd | Envelope |
1You must spell out the word "Transparency" in the string, although it is abbreviated as TRNSPRNCY on the control panel.
2The correct command for cardstock is "Esc&n11WdCard Stock", with a space between the "d" and the "S", and with an uppercase "S".
220 Chapter 6 Engineering Details | ENWW |
