Troubleshooting

Management Card Access Problems

For problems that are not described here, see the troubleshooting flowcharts on the APC Network Management Card Utility CD. Click the Troubleshooting link in the CD interface.

If the problem still persists, see “APC Worldwide Customer Support” on page 96.

Problem

Solution





Unable to ping the Management

If the Management Card’s Status LED is green, try to ping another node on

Card

the same network segment as the Management Card. If that fails, it is not a



problem with the Management Card. If the Status LED is not green, or if



the ping test succeeds, perform the following checks:



• Verify that the Management Card is properly seated in the UPS.



• Verify all network connections.



• Verify the IP addresses of the Management Card and the NMS.



• If the NMS is on a different physical network (or subnetwork) from the



Management Card, verify the IP address of the default gateway (or



router).



• Verify the number of subnet bits for the Management Card’s subnet mask.





Cannot allocate the

Before you can use a terminal program to configure the Management Card,

communications port through a

you must shut down any application, service, or program using the

terminal program

communications port.





Cannot access the command line

Make sure that you did not change the baud rate. Try 2400, 9600, 19200, or

interface through a serial

38400.

connection







Cannot access the command line

• Make sure you are using the correct access method, Telnet or Secure SHell

interface remotely

(SSH). An Administrator can enable these access methods. By default,



Telnet is enabled. Enabling SSH automatically disables Telnet.



• For SSH, the Management Card may be creating a host key. The



Management Card can take up to one minute to create the host key, and



SSH is inaccessible for that time.





Cannot access the Web interface

• Verify that HTTP or HTTPS access is enabled.



• Make sure you are specifying the correct URL — one that is consistent



with the security system used by the Management Card. SSL requires



https, not http, at the beginning of the URL.



• Verify that you can ping the Management Card.



• Verify that you are using a Web browser supported for the Management



Card. See “Supported Web browsers” on page 28.



• If the Management Card has just restarted and SSL security is being set



up, the Management Card may be generating a server certificate. The



Management Card can take up to one minute to create this certificate, and



the SSL server is not available during that time.





89

Network Management Card User’s Guide
