Panasonic KX-TG1840NZ Battery replacement, Turning the power on/off, Setting the date and time

Page 11

Preparation

Battery icon	Battery strength

7Low

When flashing: Needs to be charged.

Note:

LWhen 7flashes, recharge the handset batteries. 7 will continue to flash until the batteries have been charged for at least 15 minutes.

LIf the handset is turned off, it will be turned on automatically when it is placed on the base unit.

Battery life

After your Panasonic batteries are fully charged, you can expect the following performance:

Ni-MH batteries (700 mAh)

Operation	Operating time
While in use (talking)	20 hours max.

While not in use	170 hours max.
(standby)

Note:

LActual battery performance depends on a combination of how often the handset is in use (talking) and how often it is not in use (standby).

LBattery operating time may be shortened over time depending on usage conditions and ambient temperature.

Battery replacement

If 7 flashes even after the handset batteries have been charged for 7 hours, the batteries must be replaced.

Important:

LWe recommend the use of Panasonic rechargeable batteries noted on page 5. If you install non-rechargeable batteries and

start charging, the batteries may leak electrolyte.

LDo not mix old and new batteries.

1Press the notch on the handset cover firmly and slide it in the direction of the arrow.

2Remove the old batteries positive (S) terminal first and install the new ones. See page 10 for battery installation.

Turning the power on/off

Power on

Press {ih} for about 1 second.

LThe display will change to the standby mode.

Power off

Press {ih} for about 2 seconds.

LThe display will go blank.

Setting the date and time

Important:

LConfirm that the AC adaptor is connected.

LEnsure that w is not flashing.

1Press {j/OK}.

2Select “Handset Setup”, then press {>}.

3Select “Time Settings”, then press {>}.

11

Image 11
