Troubleshooting

7.1.7 Paper rolled in the OPC

•Description Paper is rolled up in the OPC.

Check and Cause	Solution

1. Paper is too thin.	1. Recommend to use normal paper thickness.
2. The face of paper is curled.	2. How to remove the rolled paper in the OPC.
	• Remove the paper while turning the OPC against
	the ongoing direction.
	• Clean fingerprints on the OPC softly with soft
	cloth dampened with IPA(Isopropyl Alcohol) or tis-
	sue.

7.1.8 Defective ADF

•Description ADF (Automatic document Feeder) is not properly operated.

Check and Cause	Solution

1. Check if ADF rubber and HOLDER rubber are dam-	1. Replace the contaminated or damaged part.
aged.
2. Check if the document sensors of ADF Ass’y	2. If you cannot confirm the damaged part with the
(3 paper sensors) are normal.	naked eye, try to replace the ADF Ass’y.

7-4Service Manual

Image 97
