2635A

Users Manual

Table 2-3. Thermocouple Ranges

Type

J

C***

b

S

Material

Iron

Tungsten (5% Rhenium)

Platinum (30% Rhodium)

Platinum

Positive Lead

(H)Color

ANSI* IEC**

White

Black

White



Gray



Black

Orang



e

Negative Lead

Material

Constantan

Tungsten (26% Rhenium)

Platinum (6% Rhodium)

Platinum (10% Rhodium)

Usable

Range (°C)

-200 to 760

0 to 2316

0 to 1820

-50 to 1768

R

Platinum

Black

Orang

e

Platinum (13% Rhodium)

-50 to 1768

N

NICROSIL

Orang

e

NISIL

-270 to 1300

T

Copper

Blue

Brown

Constantan

-270 to 400

E

Chromel

Purple

Violet

Constantan

-270 to 1000

K

Chromel

Yellow

Green

Alumel

-270 to 1372

*American National Standards Institute (ANSI) device negative lead (L) is always red.

**International Electrotechnical Commission (IEC) device negative lead (L) is always white.

***Not an ANSI designation but a Hoskins Engineering Company designation.

FUNC

SET FUNC

OFF

°F [°C]* Hz

Ω

VAC

V DC

Selecting the Temperature Mode. Press the FUNC key to access the SET FUNC (Set Function) menu. Press the up/down arrow keys until °C (Centigrade) or °F (Fahrenheit) is displayed, then press the ENTER key. (If the opposite temperature scale is desired, refer to Figure 2-2.)

ENTER

ENTER

Typical

Required

SET FUNC

J

K

E

T

N

R

S b

C Pt**

Selecting the Type of Thermocouple. Select the desired type of thermocouple from the menu, for example, T, then press ENTER. The "Pt" (Platinum) setting is used for RTDs only (See Figure 2-9).

*Depends on temperature scale.

**Only Pt can be selected for Channel 0.

op20f.eps

Figure 2-8. Configuring a Channel to Measure Temperature (Thermocouples)

2-14
