DR300 Operator Manual	Chapter 9 - Online Programming
Maxi Code Command
1. Command Syntax <BA>
ESC + BA NN a , b , c , d d d d d d d d d,
e e e , f f f , n n • • n
NN = field number

<1B>16 <42>16 <41>16 a , b , c , d d d d d d d d d,

e e e , f f f , n n • • n

2.	Description
	a	“Symbol number”			= Valid Range; 1-8
	b	“Number of Symbols”			= Valid Range: 1-8
				* It is necessary to specify this parameter
				when split print is done. Usually specify
				a = b = 1.
	c	“Mode”			= 2: For transfer only
					= 3: For transfer only
					= 4: Standard symbol
					= 6: For read machine only
	d	“ Postal Code”			= Valid Range: 000000-999999
				* For mode 2, specify the maximum digit to
				9 (number only) and for mode 3, the digit is
				fixed to 6 (Only Capital letters when
				alphanumerics are used)
	e	“Country Code”			= Valid Range: 001-999 (number)
	f	“Service Class”			= Valid Range: 001-999 (number)
	n	“Low Priority Message”			= Valid Range: Alphanumerics,
					Symbols.
					* 00h cannot be specified in the
					print data.
Mode	Service Class		Country Code	Postal Code		Maximum Number of Print
							Data
						Only	Combination of
						Number	alphanumerics
2	3 digit fixed		3 digit fixed	9 digit		123	84
	(only		(only	maximum
3	numeric)		numeric)	6 digit fixed
				(alphanumerics)
4	3 digits fixed		3 digits fixed	6 digits fixed		138	93
6	001		001	000000

75
