Bar Code Field, Bookland

DR300 Operator Manual	Chapter 9 - Online Programming

11)Bar Code Field

1 : Bar code designation

•Bar code without human interpretation character.

•Bar code with human interpretation character.

Digit	Designated		Designated Description
Position	Item
1, 2	Field	70 : Bar code without interpretation (w/o EAN Guide Bar)
	designation	71 : Bar code with interpretation (w/o EAN Guide Bar)
		72 : Bar code without interpretation (w/EAN Guide Bar)
		73 : Bar code with interpretation (w/EAN Guide Bar)
3	Bar code type	0 : NW-7 (Bar ratio selection YES)
		1	: CODE 39 (Bar ration selection YES)
		2	: INT 2 of 5 (Bar ratio selection YES)
		3	: EAN 13 / UPC-A
		4	: EAN 8
		5	: UPC-E
		6	: CODE 128 (B set without control code character)
		7	: CODE 128 (C set without control code character)
		8	: UCC/EAN 128
		9	: BOOKLAND
4, 5	Vertical	0000 : Input only and no printing field
6, 7	Position	001 ~ 1424 : Vertical position (dot)
8-10	Horizontal	001 ~ 640 : Horizontal position (dot)
	Position
11	Rotation	0 : 0 degree
		1	: 90 degree
		2	: 180 degree
		3	: 270 degree
12, 13	Character gap	00-99 : Character gap (dot)
		(For human interpretation character)
14, 15	Data digits	01~40 : Data digits
		*Exclude start/stop code for NW-7, Code 39
		*01-20 for Code 128
16	Bar ratio	0 : None (For EAN, etc)
		1	: 1:2
		2	: 2:5
		3	: 1:3
		4	: Flexible bar ratio (1 field/format)
		5	: Simplified NW-7 (For NW-7 only)
		6	: SATOC NW-7 (NW-7 only)
17	Horizontal	1~9 : Bar code horizontal expansion
	expansion
