Southbend STRG-5D, STRG-3D manual Suggested Cooking Times

Page 10

OPERATION

STRATOSTEAM COUNTERTOP STEAMER

SUGGESTED COOKING TIMES

These cooking times are for general guidance only. Differences in food quality, size, shape, thickness, freshness, load size, and desired degree of doneness must be taken into consideration and adjustments made in time, if necessary.

Product

Quantity

STRE-3D Cooking

STRE-5D Cooking

Time (minutes)

Time (minutes)





Eggs

18

5

6

48

6

7



Potatoes, Red

4 lbs.

18

18

8 lbs.

18

18



Rice

2 lbs.

15

16

3 lbs.

15

17



Shrimp, Frozen

2.5 lbs.

4.5

4

8 lbs.

8

7



Corn, Frozen

2.5 lbs.

3

2.5

7.5 lbs.

5

4.5



Peas, Frozen

5 lbs.

5.5

4

12 lbs.

10

8





2.5 lbs.

4

3.25

Mixed Vegetables, Frozen

8 lbs.

6.5

5.5

15 lbs. (3 full pans)

14

-





25 lbs. (5 full pans)

-

17









Salmon Filets, Frozen, 4.5 oz.

1 piece

7

7

8 pieces

7

7



Salmon Filets, Frozen, 6 oz.

8 pieces

12

10

18 pieces (3 full pans)

17

-



30 pieces (5 full pans)

-

15

Lasagna, 6 lb., Frozen

1

65

60

3

65

-



5

-

60

Cake, White, 5 lb. Mix

1 pan

30

25









PAGE 10 OF 50

OWNERS MANUAL 1185290
