Chapter 7 Application Programs

Example Programs for Excel 7.0

Excel 7.0 Example: takeReadings Macro

’""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""

’This Excel Macro (Visual Basic) configures the 34970A for scanning with the 34901A,

’34902A, or 34908A multiplexer modules. When this subroutine is executed, it will

’take the specified number of readings on the selected channel. You can easily modify the

’number of readings, channel delay, and channel number. To make these changes, modify the

’code in the section titled ’SET UP’. Note that you must have one of the above

’modules installed in slot 100 for this program to run properly. You must also have an

’GPIB interface card installed in your PC with the VISA or VTL library. ’""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""

Option Explicit Sub takeReadings()

Columns(1).ClearContents
Columns(2).ClearContents
Dim I As Integer	’ Used for counter in For-Next loop
Dim numberMeasurements As Integer	’ Number of readings
Dim measurementDelay As Single	’ Delay between relay closure and measurement
Dim points As Integer
’

’""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""

’To change the GPIB address, modify the variable ’VISAaddr’ below.

VISAaddr = "9"

OpenPort	’	Open communications on GPIB
SendSCPI "*RST"	’	Issue a Factory Reset to the instrument

’""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""

’SET UP: Modify this section to select the number of readings, channel delay,

’and channel number to be measured.

numberMeasurements	= 10	’	Number of	readings
measurementDelay =	0.1	’	Delay (in	secs) between relay closure and measurement

’Configure the function, range, and channel (see page 201 for more information). SendSCPI "CONF:VOLT:DC (@103)" ’ Configure channel 103 for dc voltage ’""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""""

’Select channel delay and number of readings

SendSCPI "ROUT:CHAN:DELAY " & Str$(measurementDelay)

SendSCPI "TRIG:COUNT " & Str$(numberMeasurements)

’Set up the spreadsheet headings Cells(2, 1) = "Chan Delay:" Cells(2, 2) = measurementDelay Cells(2, 3) = "sec"

Cells(3, 1) = "Reading #" Cells(3, 2) = "Value"

SendSCPI "INIT" Do

SendSCPI "DATA:POINTS?" points = Val(getScpi())

Loop Until points >= 1

’Remove one reading at a time from memory For I = 1 To numberMeasurements

SendSCPI "DATA:REMOVE? 1"			’ Request 1 reading from memory
Cells(I + 3, 1)		= I	’ The reading number
Cells(I + 3, 2)		= Val(getScpi())	’ The reading value
Do	’ Wait for instrument to put another reading in memory
SendSCPI "DATA:POINTS?"			’ Get the number of readings stored
points = Val(getScpi())
Loop Until points >= 1 Or I >= numberMeasurements
Next I
ClosePort	’ Close communications on GPIB

End Sub

322
