To Configure the Remote Interface
The instrument is shipped with both an GPIB (IEEE-488) interface
and an RS-232 interface. Only one interface can be enabled at a time.
The GPIB interface is selected when the instrument is shipped from
the factory.
GPIB Configuration
1 Select the GPIB (HPIB) interface.

+3,%

2 Select the GPIB address.
You can set the instrument’s address to any value between 0 and 30.
The factory setting is address “9”.

$''5(66

3 Save the change and exit the menu.
Note: Your computer’s GPIB interface card has its own address.
Be sure to avoid using the computer’s address f or any instrument on the
interface bus. Agilent’s GPIB interface cards generally use address “21”.
Interface
Interface
Chapter 2 Front-Panel Overview
To Configure the Remote Interface
46
