Creating Websites for the 4620 IP Telephone

Attribute	Value(s)	Description	Comments

ordered	true	Specifies the order of card	Optional; sets a Boolean
	false	content. When ordered is	value that provides
	false	set to "true" the browser will	information on how the
		set to "true" the browser will	information on how the
		display the content in a fixed	content of the current card is
		order. When ordered is set	arranged. Used by the
		to "false" the users will	browser to organize the
		decide the order as they	display presentation and
		navigate between content.	layout. If set to true, content
		Default is "true"	is organized in a linear
			sequence of elements (for
			example, a series of ordered
			or non-optional input
			elements). If set to false,
			content is in no natural order
			(for example, a series of
			unordered or optional input
			elements). The default is
			true. NOT SUPPORTED.

title	cdata	The title of the card	Can be used for title
			displays. SUPPORTED

onenterbackward	url	Occurs when the user	SUPPORTED
		navigates into a card using a
		“prev” task

onenterforward	url	Occurs when the user	SUPPORTED
		navigates into a card using a
		“go” task

ontimer	url	Occurs when a “timer”	SUPPORTED
		expires

■<template> tag - The <template> tag defines a template for all the cards in a deck. The "code" in the <template> tag is added to each card in the deck. Only one <template> tag for each deck may be specified. This tag can only contain <do> and <onevent> tags.

The template tag attributes supported by the 4620 web browser are as follows:

Attribute	Value(s)	Description	Comments

onenterbackward	url	Occurs when the user	SUPPORTED
		navigates into a card using a
		“prev” task

onenterforward	url	Occurs when the user	SUPPORTED
		navigates into a card using a
		“go” task

ontimer	url	Occurs when the “timer”	SUPPORTED
		expires

WML Document Skeleton

C-3
