2.Select Setup from the control panel.

3.Select + Installation to show a list of system installation specification options. (If you can't see these, select the down arrow to scroll them into view.)

4.Select Change next to Change Location of Media Storage. A data box appears, showing a list of all the available 8000i processors.

5.Select the new processor and select Set Location to confirm the new processor. The new settings are applied immediately and stay until you change them again.

6.When you are finished, select Return.

10.9Set NMEA Output

To select NMEA Output sentences:

1.Select Display.

2.Select Setup from the control panel.

3.Select + Installation to display a list of installation specification options.

4.Select Configure NMEA output.

5.Select the NMEA output to toggle between Yes / No

6.Select Save to confirm the new settings or Return to cancel.

NOTE: It is not possible to select all the parameters at the same time, due to frame rate timing. Please select only the ones required.

Sentence

Output

APA

Autopilot (subset of APB)





APB

Autopilot Sentence "B"





BEC

Bearing and Distance to Waypoint, Dead Reckoning





BOD

Bearing, Origin to Destination





BWC

Bearing and Distance to Waypoint, Great Circle





BWR

Bearing and Distance to Waypoint, Rhumb Line





BWW

Bearing, Waypoint to Waypoint





DBT

Depth Below Transducer





DPT

Depth





GGA

Global Positioning System Fix Data





GLL

Geographic Position, Latitude/Longitude





HCC

basic compass heading





HDG

Heading, Deviation and Variation





HDM

Magnetic Heading





HDT

Heading, True





HSC

Heading Steering Command





MWD

Wind direction and speed





MWV

Wind Speed and Angle





RMB

Recommend Minimum Navigation Information





RMC

Recommend Minimum Specific GPS / TRANSIT Data





VHW

Water Speed and Heading





VTG

Track Made Good and Ground Speed





Northstar 8000i System - 12" Display Processor Installation Manual
