P o s t S c r i p t S I M M

8 Replace the power and interface cables and power ON the printer.

After warming up for a few minutes, the Control Panel displays the following message:

Online

Ready

If any other message is displayed, see Table 6.2 starting on page 6-6.

9 Print a Configuration Sheet to verify that the SIMM has been installed properly.

A Press Online to take the printer offline.

BPress Menu , then Down or Up until you see:

Main Menu Test Menu

CPress Enter and the message display changes to:

Test Menu Config. sheet

DPress Enter again to print a Configuration Sheet.

EAfter the Configuration Sheet prints, press Online to put the printer back online.

The Configuration Sheet should show the PostScript Menu and PostScript version.

10 Install a Digital LN17 PostScript print driver now.

Table 2 in the Setting Up Guide lists the LN17 PostScript printer drivers packaged with your printer. See the Setting Up Guide for installing driving software.

C-12❖ L N 1 7 a n d L N 1 7 p s P r i n t e r s U s e r G u i d e
