E n v e l o p e F e e d e r

Removing the

Envelope Feeder

1 Power OFF the printer and disconnect both power cords and any interface cables.

2 Lift the Envelope Feeder up and out from	3 Re-attach the face plate that was removed
the printer.	when the Envelope Feeder was installed.

Store the Envelope Feeder in its original packaging materials, or in a dry, dust-free place.

4

5

Close the hinged clasp at the left side of the Front Tray.

Close the Front Tray if not needed.

Reconnect the power cord and interface cable(s) and power ON the printer.

After warming up for a few minutes, the Control Panel displays the following message:

Online

Ready

If any other message is displayed, see Table 6.2 starting on page 6-6.

C-46❖ L N 1 7 a n d L N 1 7 p s P r i n t e r s U s e r G u i d e
