MaxLoader User’s Guide

Device / Auto

Auto command will enable you to execute a operation steam that are selected in auto menu option It will execute all commands sequentially and it is useful to program a volume quantity devices with the same data.

CAUTION: Some devices such as Philips P98C52 can be passed the BLANK CHECK routine after they are secured even though it is not in blank status.

Test (This feature is for only TopMax, TopMaxII)

Test / RAM Test

TopMax, TopMaxII provide an additional memory test function. This operation tests static and dynamic RAM memory chips. The following memories are tested:

DRAM types tested

-16K*4, 64K*1, 64K*4, 256K*1, 256K*4, 1M*1

SRAM type tested

-2K*8, 8K*8, 32K*8, 128K*8
