ESG Family Signal Generators

201 to 702: Device-Specific Errors

201 to 702: Device-Specific Errors

Some device operations did not properly complete, possibly due to an abnormal hardware or firmware condition. These codes are also used for self-test response errors. Errors in this class set the device-specific error bit (bit 3) in the event status register (IEEE 488.2, section 11.5.1).

The <error_message> string for a positive error is not defined by SCPI. A positive error indicates that the instrument detected an error within the GPIB system, within the instrument’s firmware or hardware, during the transfer of block data, or during calibration.

201Bad file number; Unable to check Data Generator memory.

The instrument was not able to generate the pattern necessary to perform the data generator memory test. This does NOT imply a data generator memory failure. Report this error to the nearest Agilent Technologies sales or service office.

208I/O Error; <file name>

Invalid file name.

I/O error; Delete a non-saved state register. Delete register ignored.

The user has attempted to delete an unused (empty) state. This error message is informational only.

I/O error; Delete empty sequence <sequence_name>. Delete sequence ignored.

The user has attempted to delete a sequence that is empty. This error message is informational only. Typically, this error is reported several times when the “Delete All Sequences” command is executed. If the file is displayed by Catalog, delete explicitly.

I/O error; Directory does not have a default file type.

Report this error to the nearest Agilent Technologies sales or service office.

I/O error; Directory refuses to release ownership.

Report this error to the nearest Agilent Technologies sales or service office.

I/O error; Save a state register ignored.

Error Messages

55
