Cisco Systems CF2001P user manual Date/Time Settings

Page 39

CF2001P

NEXT

2. Click [Dial Mode].

<Date/Time Settings>

1. Click [Date/Time Input].

C4656P004CA

3.Select the dial mode of the user’s telephone line.

Push-button

[Tone]

Rotary

[Pulse]

4. Click [END].

C4656P005CA

5. Click [Auto Receive].

C4656P003CA

2.Click [Year], click the Clear key in the External Panel Controller, and then use the keypad in the External Panel Controller to enter the correct year.

3.Enter the correct settings for [Month], [Date], and [Hour].

C4656P007CA

4. Click [SET].

C4656P004CA

6.Click [Disable].

7.Click [END] twice.

C4656P006CA

4004-7715-01

– 38 –
