Note:
•The buttons [VGA] and [QVGA] are displayed only when "4:3" is selected for "Aspect ratio".
•The buttons [640x360] and [320x180] are displayed only when "16:9" is selected for "Aspect ratio".
•When "1280x960" or "1280x720" is selected for the image capture size, it may become smaller than the actual size depending on the window size of the web browser.
y[Zoom] buttons
[x1] button: The letter "x1" will turn green and images in the main area will be displayed at x1.
[x2] button: The letter "x2" will turn green and images in the main area will be displayed at x2.
[x4] button: The letter "x4" will turn green and images in the main area will be displayed at x4.
u[Brightness] buttons*2
[–](darker) button: The displayed image will be darker.
[Normal] button: The adjusted brightness will return to the default brightness.
[+] (brighter) button: Image will be brighter.
i Camera title
The camera title entered for "Camera title" on the [Basic] tab will be displayed. (☞ Page 17)
oAlarm occurrence indication button*2
This button will be displayed and will blink when an alarm has occurred. When this button is clicked, the button will disappear. (☞ Page 10)
!0Full screen button
Images will be displayed on a full screen. (The aspect ratio of displayed images will be adjusted in accordance with the monitor.) To return to the "Live" page, press the [Esc] key.
!1One shot button
Click this button to take a picture (a still picture). The picture will be displayed on a newly opened window. When
When "Print" is selected, printer output is enabled.
!2Main area
Images from the camera will be displayed in this area.
The current time and date will be displayed accord- ing to the settings configured for "Time display for- mat" and "Date/time display format". (☞ Page 17)
When clicking a desired point while displaying live images at x2 or x4 in the main area, the camera will move to locate the clicked point at the center of the main area.
*1 Only operable by users whose access level is "1. Administrator".
*2 Only operable by users whose access level is "1. Administrator" or "2. Camera control" when "On" is selected for "User auth." (☞ page 38).
Note:
•When operated by a lower access level user, images displayed on the screen may be changed temporar- ily. This does not affect operation of the camera.
•A zoom operation can be performed using the mouse wheel.
•Depending on the PC in use, the top and bottom of the images may be displayed out of alignment.
8
