HP NX9500 manual Removing the Memory Module/Mini PCI Compartment Cover

Removal and Replacement Procedures

1.Prepare the notebook for disassembly (refer to Section 5.3).

2.Turn the notebook upside down with the rear panel toward you.

3.Loosen the 2 PM2.5×4.0 screws 1 that secure the memory module/Mini PCI compartment cover to the notebook.

4.Slide the cover 2 toward you, and then lift the cover up 3.

5.Remove the cover 4.

✎The memory module/Mini PCI compartment cover is included in the Miscellaneous Plastics Kit, spare part number 344852-001 for use with HP zd7000 models, or spare part number 370805-001 for use with HP Compaq nx9500 models.

Removing the Memory Module/Mini PCI Compartment Cover

Maintenance and Service Guide 5–11
