Removal and Replacement Procedures
5.14 Heat Sink
Spare Part Number Information
Heat sink (includes large and small fans and thermal paste) | |
|
|
Thermal Paste Kit | |
|
|
1.Prepare the notebook for disassembly (Section 5.3) and remove the following components:
❏Optical drive (Section 5.7)
❏Keyboard (Section 5.8)
❏Keyboard cover (Section 5.9)
❏Display assembly (Section 5.10)
❏Top cover (Section 5.11)
❏System board (Section 5.12)
2.Turn the system board upside down with the rear panel facing you.
