Removal and Replacement Procedures
5.13 RTC Battery
✎The RTC battery is included in the Miscellaneous Plastics Kit, spare part number
1.Prepare the notebook for disassembly (Section 5.3) and remove the following components:
❏Optical drive (Section 5.7)
❏Keyboard (Section 5.8)
❏Keyboard cover (Section 5.9)
❏Display assembly (Section 5.10)
❏Top cover (Section 5.11)
❏System board (Section 5.12)
2.Turn the system board upside down with the rear panel toward you.
3.Remove the RTC battery from the socket.
Removing the RTC Battery
Reverse the above procedure to install the RTC battery.
Maintenance and Service Guide |
